Document pipelines: parsing, cleaning and chunking

Learn in your browser · Chapter 01 of 06

A retrieval system can only find evidence that reached its index intact. This lab builds the small, inspectable stage between an extracted text document and a set of traceable passages. Start by deciding what the input represents and which failures must remain visible.

Imagine a fictional workshop with a short kit-loan policy. A learner asks how long a kit can be borrowed and where it must be returned. If a pipeline drops the return instruction, an excellent search algorithm cannot recover it. If two unrelated documents receive the same identifier, a correct passage may be cited as the wrong source. These are ingestion defects before they are model defects. The fixtures below are invented teaching data, not Mickai policies or measurements.

Separate acquisition, extraction, normalisation, chunking and indexing. Acquisition selects an authorised source revision. Extraction obtains text and structural information from its format. Normalisation applies explicit transformations. Chunking creates retrieval units. Indexing publishes those units with a lifecycle. Keep a small manifest so a failed file cannot disappear silently from the batch count.

Scroll sideways to see every column.

The implemented exercise accepts only bytes containing UTF-8 text, optionally beginning with a byte-order mark. It is not an HTML or PDF parser. A real adapter would need to produce text plus useful page, section or coordinate metadata first. The pypdf documentation explains why PDF text extraction is difficult and distinguishes text extraction from OCR. A selectable text layer is useful evidence, but it still needs checking against the visible document when layout matters.

Make missing content observable. Empty output can mean an intentionally blank document, a scanned image without OCR, a failed extractor or an incorrect selection rule. Do not silently label all four cases as ready. This lab returns an empty status for text without words and raises errors for invalid input. A batch runner should count each outcome, retain a reason and route doubtful material to review. It should not replace an earlier valid index with an unexplained empty result.

Learn in your browser · Chapter 02 of 06

Cleaning is a policy decision. It should remove known representational noise without silently changing the evidence. Preserve source bytes or an authorised immutable reference, and label the coordinate system used by the cleaned text.

Create an empty folder for this exercise and save the following code as pipeline.py. Use Python 3.12 or a compatible version; the recorded execution for this course uses Python 3.12.10 on Windows 11. No additional packages, model accounts or network calls are required. The file is deliberately built in two parts: the function continues in the next chapter. Do not try to run a half-copied function as the final lab.

import hashlib
import json
import re
import unicodedata

POLICY = "word-window-v1"


def normalise(raw):
    if not isinstance(raw, bytes):
        raise TypeError("raw must be bytes")
    text = raw.decode("utf-8").removeprefix("\ufeff")
    if "\x00" in text:
        raise ValueError("NUL is outside this text contract")
    text = text.replace("\r\n", "\n").replace("\r", "\n")
    return unicodedata.normalize("NFC", text)


def chunk_document(doc_id, raw, max_words=8, overlap=2):
    if not isinstance(doc_id, str) or not doc_id.strip():
        raise ValueError("doc_id must be a non-empty string")
    if type(max_words) is not int or max_words < 1:
        raise ValueError("max_words must be a positive integer")
    if type(overlap) is not int or not 0 <= overlap < max_words:
        raise ValueError("overlap must be an integer below max_words")
    text = normalise(raw)
    raw_hash = hashlib.sha256(raw).hexdigest()
    text_hash = hashlib.sha256(text.encode("utf-8")).hexdigest()
    spans = list(re.finditer(r"\S+", text))
    chunks = []
    step = max_words - overlap

The input is decoded strictly. Malformed UTF-8 raises an exception rather than substituting a replacement character that might disguise a damaged identifier or amount. The policy removes one leading byte-order mark, converts common newline encodings to LF and applies Unicode NFC. Python documents NFC as canonical normalisation; compatibility normalisation is a different choice. This course does not silently lowercase text, remove punctuation or merge every line.

The raw hash identifies these exact input bytes. The text hash identifies the normalised UTF-8 text. Two files can have the same cleaned text and different raw hashes, for example after a newline change. Keeping both helps explain that distinction. A hash is not a signature, an access-control decision or proof that a source is truthful. The lab uses SHA-256 for repeatable content fingerprints, as provided by Python hashlib.

Offsets in later chunks refer to the normalised Python string. They are not original file byte positions, page coordinates, model tokens or JavaScript string offsets. Normalisation can change string length. Save the cleaned revision with its hash if you need to reproduce a slice later. To highlight the original PDF you need a separate mapping supplied by the extraction stage; counting characters in its text is not a substitute.

Avoid universal cleaning rules. Joining all line breaks could damage a poem, a table or code indentation. Removing every repeated line could erase a repeated safety warning. Deleting punctuation could alter a decimal number or a command. For the workshop policy, inspect the three sentences and retain their boundaries. If you later add a transformation, give the pipeline a new policy version and test representative material before replacing the index.

Learn in your browser · Chapter 03 of 06

A chunk needs both content and a way back to its source. Finish the function by constructing windows over explicit word positions, recording character spans and including the processing policy in each identifier.

Append this indented continuation directly after step = max_words - overlap in pipeline.py. The regular expression finds runs of non-whitespace characters. We call those runs words for the exercise; they are neither linguistic word segmentation nor a model tokenizer. The step is positive because overlap must be smaller than the window. The final break prevents an unnecessary extra tail once a window has already reached the last word.

    for start in range(0, len(spans), step):
        end = min(start + max_words, len(spans))
        lo = spans[start].start()
        hi = spans[end - 1].end()
        identity = [POLICY, doc_id, raw_hash, text_hash,
                    max_words, overlap, start, end]
        encoded = json.dumps(identity, separators=(",", ":"))
        chunk_id = hashlib.sha256(encoded.encode("utf-8")).hexdigest()
        chunks.append({
            "id": chunk_id, "doc_id": doc_id,
            "raw_sha256": raw_hash, "text_sha256": text_hash,
            "policy": POLICY,
            "max_words": max_words, "overlap": overlap,
            "word_start": start, "word_end": end,
            "char_start": lo, "char_end": hi,
            "text": text[lo:hi],
        })
        if end == len(spans):
            break
    return {"text": text, "chunks": chunks,
            "status": "ready" if chunks else "empty"}

Word ranges use a zero-based start and an exclusive end. A range from 6 to 14 contains eight whitespace units. Character ranges use the same half-open convention and preserve the whitespace between the selected first and last units. Leading and trailing whitespace outside those units is not part of any chunk. That is an intentional contract, so a coverage test should require every word, not every whitespace character, to be covered.

The ID includes the document identity, both hashes, policy name, sizes and word range. Repeating the same inputs produces the same records. Changing the document identity, raw revision or window policy produces a different identity even when a visible passage looks similar. This prevents this exercise from collapsing two distinct source records just because their text matches. Your document identifiers must themselves come from a trustworthy, stable upstream scheme.

Version the implementation honestly. The policy string names this algorithm, but it does not automatically detect a code change. If you alter splitting or normalisation, update the policy and record the tested implementation revision. Downstream, use that revision to rebuild and reconcile old chunks. Do not leave both old and new windows indefinitely searchable merely because their IDs differ. Plan an atomic index generation or another tested replacement process.

This implementation materialises the full text, a match list and every result in memory. It has no file-size ceiling or streaming adapter. Use the small supplied fixtures only. Before connecting uploads, add format and resource bounds appropriate to the actual ingestion service. Store source permissions with a real authorisation design outside this example; an ID or hash alone must never confer access to a chunk.

Learn in your browser · Chapter 04 of 06

Run a transparent fixture and look at what each window actually contains. The first useful review is whether a learner can trace a passage and whether the evidence needed for an answer remains together.

Save the following file as demo.py beside pipeline.py. Run python demo.py in that folder. The main guard keeps importing RAW into another script quiet. All text is invented. The blank line and newline are retained within windows, so repr displays them as escapes instead of creating misleading extra output lines.

from pipeline import chunk_document

RAW = (b"Workshop loan policy.\n\n"
       b"Borrowers may keep a kit for seven days.\n"
       b"Return kits to the desk.")

if __name__ == "__main__":
    result = chunk_document("workshop-loans-v1", RAW)
    for row in result["chunks"]:
        print(row["word_start"], row["word_end"],
              repr(row["text"]))

0 8 'Workshop loan policy.\n\nBorrowers may keep a kit'
6 14 'a kit for seven days.\nReturn kits to'
12 16 'kits to the desk.'

The borrowing duration is complete in the second window. The return instruction is split: one window stops after to and the next starts after Return. Overlap repeats words but does not necessarily preserve every useful statement. A window can also combine the end of one section with the start of another. Examine boundaries rather than treating the existence of overlap as proof of semantic completeness.

For a structured policy collection, a later design could use headings and paragraphs as primary boundaries, splitting an oversized section only when necessary. Keep heading context as explicit metadata or clearly labelled context text rather than silently adding it to the quoted passage. Record any such added text separately so a citation slice still reproduces the source span. Lists, tables and code need their own fixtures; the whitespace splitter is a baseline, not a universal document strategy.

Check provenance by slicing result["text"] with the recorded character bounds and comparing it with each row. Keep an ID-to-source-revision mapping when storing records. If a citation points to a later edited document, the quoted passage may no longer exist at those offsets. Retaining the cleaned revision permits local verification, while retaining an original reference allows a reader to understand where that text came from.

Learn in your browser · Chapter 05 of 06

Use two kinds of evidence: deterministic checks of the pipeline contract and a small content check of what survives together. Neither one measures a deployed search engine or the quality of a model answer.

Save the next block as compare.py and run python compare.py. Each fixture fact is an exact, manually selected evidence string. A hit means one chunk contains that entire string. This is a deliberately narrow ingestion check. It is not retrieval recall, semantic equivalence or evidence that a model answered correctly. The facts, sizes and results below describe only the sixteen-word policy.

from pipeline import chunk_document
from demo import RAW

FACTS = ("Workshop loan policy.",
         "a kit for seven days.",
         "Return kits to the desk.")

for size, overlap in [(8, 0), (8, 2), (10, 4)]:
    rows = chunk_document("workshop-loans-v1", RAW,
                          size, overlap)["chunks"]
    covered = sum(any(fact in r["text"] for r in rows)
                  for fact in FACTS)
    occurrences = sum(r["word_end"] - r["word_start"]
                      for r in rows)
    print(size, overlap, len(rows), covered, occurrences)

Scroll sideways to see every column.

Overlap changes which evidence survives; the middle setting does not improve the total. More repeated words also consume storage and potentially context. Counts here exclude metadata and tokenizer behaviour, so they cannot be converted directly into embedding cost. For a real decision, keep a varied labelled set, retrieve against fixed queries and inspect ranked results and grounded answers separately. Use held-out cases to reduce tuning to a few convenient examples.

Save the next code as test_pipeline.py. Run python -m unittest -v test_pipeline. These tests specify observable requirements: known ranges, exact slices, explicit empty status, invalid input rejection, no redundant tail and repeatable identities. They run locally with the standard library. The course release also checks a larger matrix of window/overlap lengths and malformed inputs; those additional checks do not replace representative document review.

import unittest
from pipeline import chunk_document, normalise
from demo import RAW


class PipelineTests(unittest.TestCase):
    def test_windows_and_slice_provenance(self):
        result = chunk_document("fixture", RAW)
        rows = result["chunks"]
        self.assertEqual([(r["word_start"], r["word_end"])
                          for r in rows], [(0, 8), (6, 14), (12, 16)])
        for r in rows:
            self.assertEqual(r["text"], result["text"][
                r["char_start"]:r["char_end"]])

    def test_empty_is_not_ready(self):
        result = chunk_document("empty", b" \n\t")
        self.assertEqual(result["status"], "empty")
        self.assertEqual(result["chunks"], [])

    def test_invalid_utf8_fails(self):
        with self.assertRaises(UnicodeDecodeError):
            normalise(b"\xff")

    def test_invalid_overlap_fails(self):
        for bad in [-1, 8, 9, True, 1.5]:
            with self.subTest(overlap=bad):
                with self.assertRaises(ValueError):
                    chunk_document("fixture", RAW, 8, bad)

    def test_exact_end_has_no_redundant_tail(self):
        rows = chunk_document("small", b"a b c d", 4, 2)["chunks"]
        self.assertEqual(len(rows), 1)

    def test_ids_repeat_and_change_with_source(self):
        first = chunk_document("fixture", RAW)["chunks"]
        again = chunk_document("fixture", RAW)["chunks"]
        other = chunk_document("different", RAW)["chunks"]
        self.assertEqual(first, again)
        self.assertNotEqual(first[0]["id"], other[0]["id"])


if __name__ == "__main__":
    unittest.main()

Challenge a test with a deliberate defect in a disposable copy. Remove the break after end == len(spans), leaving a pass so the Python syntax stays valid. The exact-end test should now fail for four words with overlap two because a redundant tail appears. Restore the correct code and rerun. This demonstrates detection of that particular bug, not that the tests discover every possible pipeline defect.

Learn in your browser · Chapter 06 of 06

A useful final deliverable explains which sources were processed, what changed and what remains untested. Treat the index as a derived release with its own replacement and deletion behaviour.

For the workshop lab, record the fictional document ID, raw and cleaned hashes, policy, exact parameters, Python version, chunk count, total word occurrences and test outcome. Record empty and failed documents alongside successful ones. Keep sensitive source content out of casual logs; operational evidence can use identifiers and counts while protected diagnostic material remains in the appropriate store. This exercise contains no personal information.

Plan update behaviour before an index accumulates history. A source edit produces a new raw hash and chunk IDs. Prepare the replacement generation, validate it and switch the intended reader view. Define when obsolete chunks are removed and how failure rolls back. If an upstream source is withdrawn, address derived chunks, embeddings, caches and backups according to the real system lifecycle. The lab performs no index writes or deletion and establishes none of those operational properties.

Review a small release matrix: ordinary text, blank input, malformed encoding, a heading with a short paragraph, a long line, a table and a document without spaces. Our whitespace rule turns a continuous unspaced passage into one unit, which is a poor size control for that material. Model-token limits and multilingual segmentation require a different measured implementation. Mark unsupported formats explicitly rather than accepting them because a string was returned.

Source freshness and permission are separate from text quality. A perfectly extracted obsolete policy is still obsolete. A clean private paragraph is still private. Carry source revision and access metadata through the ingestion and retrieval architecture, and enforce access where requests are served. Also treat retrieved text as evidence data, not permission for an agent to execute instructions found inside it. Chunking does not resolve either authorisation or prompt injection.
